Product Details
- Size: 12450mm*2490mm*1575mm
- Place of Origin: Jining
- Brand Name: HUAYU
- Model Number: LHY9403
- Weight: 71000.000 kg
| Tare Weight | About 7.1T |
| dimension | 12450mm*2490mm*1575mm |
| Loading Capacity | ≤45T |
| Axle | 13T/16T,FUWA/BPW/Huajing Brand |
| Rim | 9.00-22.5 |
| Tire | 12.00R22.5/315 80R22.5 |
| Suspension | Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW Brand) |
| Spring leaf | 90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12 |
| King pin | Jost brand 2.0 0r 3.5 inch bolts type or welding type |
| Suppot leg | JOST brand D200T or China brand 28Tons (Double speed) |
| Main beam | Height:500mm,upon plate is 14mm,middle plate is 8mm,down plate is 16mm;Material is Q345B Steel |
| Side beam | 16mm or 18mm channal steel (Material is Q235steel) |
| Brake chamber | WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber |
| ABS | Optional |
| Twist Locks | Four,Eightor Twelve pieces(Lifting type or Twist Screw Type) |
| Valve | WABCO valve |
| Light | LED light |
| Voltage | 24V |
| Receptacle | 7 ways(7 wire harness) |
| Tool box | One piece,1m*0.5m*0.5m(Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
| Painting | Complete Chassis sand blasting to clean rust,1 coat of anticorrosive prime,2coats of final paint |
| Shipping term | Transport by bulk cargo carrier,RORO or 40HQ container |
